FrameSpark Alloy SL 6011Integrated Suspension TechnologyFlex Pivot / Adjustable head angleSyncros Cable Integration SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline
ForkRockShox Pike RL3 AirCustom Charger 3-Mode Damper15x110mm Maxle Lite / 44mm offset / Tapered steererLockout / Reb. Adj. / 130mm travel
Rear ShockRockShox Deluxe Select RL3 Trunnion3 modes / Lockout-Trail-DescendDebon Air / Reb. Adj.Travel 120mm / T165X45mm
Remote SystemSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
Rear DerailleurSRAM GX Eagle 12 Speed
ShiftersSRAM NX Eagle Trigger
CranksetSRAM X1 Eagle DUB55mm CL / 32T
BB-SetSRAM DUB PF 92 MTB Wide / shell 41x92mm
ChainSRAM CN NX Eagle
CassetteSRAM SX-PG1210 / 11-50 T
BrakesShimano MT501 Disc
RotorShimano SM-RT54 CL / F&R 180mm
HandlebarSyncros Fraser 2.0 DC Alloy 6061 D.B.mini Rise / back sweep 8° / 760mmSyncros Performance XC lock-on grips
H'stemSyncros DC 3.0Syncros Cable Integration System0° rise / 6061 Alloy / 31.8mm / 1 1/8"
SeatpostSyncros Duncan Dropper Post 2.031.6mm / S size 100mm/ M size 125mm / L size 150mm / XL size 170mm
SeatSyncros Tofino 2.5 Regular
HeadsetSyncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)Formula CL-811 / 15x110mm
Hub (Rear)Formula CL-148S / 12x148mmSyncros Axle w/Removable Leverwith 6mm AllenT30 and T25 Tools
SpokesStainless Black 15G / 1.8mm
RimsSyncros X-30SE / 32H / 30mm
Front TireSchwalbe Wicked Will 29x2.4"Performance / TLR / Foldable / Addix
Rear TireSchwalbe Wicked Will / 29x2.4"Performance / TLR / Foldable / Addix
ExtrasSyncros Fork Fender
Approx weights in KG14.5 (with tubes)
Approx weights in LBS31.97 (with tubes)
Max. System Weight128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
